Double Toggle Jaw Crusher
A Double Toggle Jaw Crusher is a type of crusher in which the moving jaw is suspended from an eccentric shaft that is situated at the top of the crusher. The moving jaw is supported by toggle plates, and the crushing process is initiated when the toggle plates move towards the fixed jaw.
The double toggle design allows for a larger feed size compared to a single toggle jaw crusher. This type of crusher has two toggle plates instead of one, which creates a higher crushing force and a more uniform output size.
In a double toggle jaw crusher, the movement of the swinging jaw is achieved by the vertical motion of the pitman. As the eccentric shaft rotates, the toggle plates push and pull the swinging jaw, creating a compressive action.
Double toggle jaw crushers are commonly used in heavy-duty mining, quarrying, and recycling applications, as they are capable of handling large feed sizes and high production capacities.
Some advantages of a double toggle jaw crusher include its ability to crush hard and abrasive materials, its higher throughput compared to a single toggle jaw crusher, and its durable construction.
Overall, the double toggle jaw crusher is a robust and reliable machine widely used in various industries for primary crushing of materials.
